This class is intended to store all the necessary data about an ANITA event for filtering and analysis. It stores the raw and filtered waveforms as well as auxilliary information. More...

#include <FilteredAnitaEvent.h>

Inheritance diagram for FilteredAnitaEvent:

[legend]

Collaboration diagram for FilteredAnitaEvent:

[legend]

Public Member Functions
int	checkSaturation (ULong64_t save_hsat=0, ULong64_t save_vsat=0, double threshold=1500) const

int	checkStepFunction (Int_t lab=1, AnitaRing::AnitaRing_t ring=AnitaRing::kMiddleRing, Int_t phiSector=8, AnitaPol::AnitaPol_t pol=AnitaPol::kVertical) const

int	checkSurfForGlitch (Int_t surf=0, Int_t lab=-1, double glitchThreshold=800) const

	FilteredAnitaEvent (const UsefulAnitaEvent event, FilterStrategy strategy, const Adu5Pat pat, const RawAnitaHeader header, bool keep_all_stages=false)

	FilteredAnitaEvent (const FilteredAnitaEvent fEv, FilterStrategy strategy, bool keep_all_stages=false)

	FilteredAnitaEvent ()

int	getAnitaVersion () const

double	getAveragePower (AnitaPol::AnitaPol_t pol=AnitaPol::kNotAPol, AnitaRing::AnitaRing_t ring=AnitaRing::kNotARing, bool filtered=false) const

void	getAverageSpectrum (TGraph *target, AnitaPol::AnitaPol_t pol=AnitaPol::kNotAPol) const

const AnalysisWaveform *	getFilteredGraph (UInt_t i) const

const AnalysisWaveform *	getFilteredGraph (UInt_t ant, AnitaPol::AnitaPol_t pol) const

const AnalysisWaveform *	getFilteredGraph (UInt_t phi, AnitaRing::AnitaRing_t ring, AnitaPol::AnitaPol_t pol) const

const AnalysisWaveform *	getFilteredGraphAtStage (UInt_t ant, AnitaPol::AnitaPol_t pol, UInt_t stage) const

const UsefulAdu5Pat *	getGPS () const

const RawAnitaHeader *	getHeader () const

double	getMedianPower (AnitaPol::AnitaPol_t pol=AnitaPol::kNotAPol, AnitaRing::AnitaRing_t ring=AnitaRing::kNotARing, bool filtered=false) const

void	getMedianSpectrum (TGraph *target, AnitaPol::AnitaPol_t pol=AnitaPol::kNotAPol, double pctile=0.5) const

void	getMinMaxRatio (AnitaPol::AnitaPol_t pol, double max_ratio, double min_ratio, int max_sector, int min_sector, AnitaRing::AnitaRing_t ring1=AnitaRing::kBottomRing, AnitaRing::AnitaRing_t ring2=AnitaRing::kTopRing, int nth=0, int *n_greater=0) const

const AnalysisWaveform *	getRawGraph (UInt_t i) const

const AnalysisWaveform *	getRawGraph (UInt_t ant, AnitaPol::AnitaPol_t pol) const

const AnalysisWaveform *	getRawGraph (UInt_t phi, AnitaRing::AnitaRing_t ring, AnitaPol::AnitaPol_t pol) const

const FilterStrategy *	getStrategy () const

const UsefulAnitaEvent *	getUsefulAnitaEvent () const

void	plotSummary (TCanvas chpol=0, TCanvas cvpol=0) const

virtual	~FilteredAnitaEvent ()

Protected Member Functions
void	saveStage (int nreserve)

Protected Attributes
std::vector< AnalysisWaveform * >	all_stages [AnitaPol::kNotAPol][NUM_SEAVEYS]

int	anitaVersion

AnalysisWaveform *	filteredGraphs [NUM_SEAVEYS *AnitaPol::kNotAPol]

AnalysisWaveform *	filteredGraphsByAntPol [AnitaPol::kNotAPol][NUM_SEAVEYS]

const RawAnitaHeader *	header

bool	keep_all_stages

UsefulAdu5Pat	pat

AnalysisWaveform *	rawGraphs [NUM_SEAVEYS *AnitaPol::kNotAPol]

AnalysisWaveform *	rawGraphsByAntPol [AnitaPol::kNotAPol][NUM_SEAVEYS]

const FilterStrategy *	strategy

const UsefulAnitaEvent *	useful

Friends
class	FilterOperation

class	FilterStrategy

Detailed Description

This class is intended to store all the necessary data about an ANITA event for filtering and analysis. It stores the raw and filtered waveforms as well as auxilliary information.

Definition at line 23 of file FilteredAnitaEvent.h.

Constructor & Destructor Documentation

◆ FilteredAnitaEvent() [1/3]

FilteredAnitaEvent::FilteredAnitaEvent	(	const UsefulAnitaEvent *	event,
		FilterStrategy *	strategy,
		const Adu5Pat *	pat,
		const RawAnitaHeader *	header,
		bool	keep_all_stages = `false`
	)

Create a FilteredAnitaEvent from a useful event, a filter strategy, GPS info and the event header. If keep_all_stages is true, then all stages of filtering are kept. Note that filtering occurs during construction, not later!

◆ FilteredAnitaEvent() [2/3]

FilteredAnitaEvent::FilteredAnitaEvent	(	const FilteredAnitaEvent *	fEv,
		FilterStrategy *	strategy,
		bool	keep_all_stages = `false`
	)

Created a FilteredAnitaEvent from another FilteredAnitaEvent. !THIS IS NOT A COPY CONSTRUCTOR! The output of fEv will be used as an input to create this filtered event. Useful for doing things like deconvolving the output of another filter. If keep_all_stages is true, then all stages of filtering are kept. Note that filtering occurs during construction, not later!

◆ FilteredAnitaEvent() [3/3]

FilteredAnitaEvent::FilteredAnitaEvent ( )

Empty FilteredAnitaEvent. Not particularly useful

◆ ~FilteredAnitaEvent()

virtual FilteredAnitaEvent::~FilteredAnitaEvent ( )

virtual

Destructor

Member Function Documentation

◆ getAverageSpectrum()

void FilteredAnitaEvent::getAverageSpectrum	(	TGraph *	target,
		AnitaPol::AnitaPol_t	pol = `AnitaPol::kNotAPol`
	)		const

Various calculations. Don't necessarily have to be in this class.

◆ getFilteredGraph() [1/3]

const AnalysisWaveform* FilteredAnitaEvent::getFilteredGraph ( UInt_t i ) const

inline

Accessor for filtered waveform based on index. Mostly useful if you want to iterate over everything

Definition at line 59 of file FilteredAnitaEvent.h.

◆ getFilteredGraph() [2/3]

const AnalysisWaveform* FilteredAnitaEvent::getFilteredGraph	(	UInt_t	ant,
		AnitaPol::AnitaPol_t	pol
	)		const

inline

Accessor for filtered waveform based on antenna number and polarization.

Definition at line 62 of file FilteredAnitaEvent.h.

◆ getFilteredGraph() [3/3]

const AnalysisWaveform* FilteredAnitaEvent::getFilteredGraph	(	UInt_t	phi,
		AnitaRing::AnitaRing_t	ring,
		AnitaPol::AnitaPol_t	pol
	)		const

Accessor for raw waveform based on phi, ring, and pol

◆ getGPS()

const UsefulAdu5Pat* FilteredAnitaEvent::getGPS ( ) const

inline

Return the Useful GPS info

Definition at line 74 of file FilteredAnitaEvent.h.

◆ getHeader()

const RawAnitaHeader* FilteredAnitaEvent::getHeader ( ) const

inline

Return the header

Definition at line 77 of file FilteredAnitaEvent.h.

◆ getRawGraph() [1/3]

const AnalysisWaveform* FilteredAnitaEvent::getRawGraph ( UInt_t i ) const

inline

Accessor for raw waveform based on index. Mostly useful if you want to iterate over everything

Definition at line 50 of file FilteredAnitaEvent.h.

◆ getRawGraph() [2/3]

const AnalysisWaveform* FilteredAnitaEvent::getRawGraph	(	UInt_t	ant,
		AnitaPol::AnitaPol_t	pol
	)		const

inline

Accessor for raw waveform based on antenna number and polarization.

Definition at line 53 of file FilteredAnitaEvent.h.

◆ getRawGraph() [3/3]

const AnalysisWaveform* FilteredAnitaEvent::getRawGraph	(	UInt_t	phi,
		AnitaRing::AnitaRing_t	ring,
		AnitaPol::AnitaPol_t	pol
	)		const

Accessor for raw waveform based on phi, ring, and pol

◆ getStrategy()

const FilterStrategy* FilteredAnitaEvent::getStrategy ( ) const

inline

Return the strategy

Definition at line 80 of file FilteredAnitaEvent.h.

◆ getUsefulAnitaEvent()

const UsefulAnitaEvent* FilteredAnitaEvent::getUsefulAnitaEvent ( ) const

inline

Return the UsefulAnitaEvent this event was constructed with.

Definition at line 72 of file FilteredAnitaEvent.h.

The documentation for this class was generated from the following file:

include/FilteredAnitaEvent.h
